37
PME-MP55
HBMA0563-5.6 en
Group Parameter Meaning
Additional
function
>0< Rf
ÇÇÇÇÇÇÇÇÇ
ÇÇÇÇÇÇÇÇÇ
Absolute zero point
Relative zero point of
transducer
Displacement
transducers
"20 mm
Zero offset= -1000 mm
Engine seating
Zero reference
Example:
A displacement transducer 〈"20 mm nominal displacement) is fastened
at a height of 1m measured from the engine seating. When setting zero,
the analogue output is balanced to 0V. The display value is adjusted to
>0<Ref (+1000 mm).The display is to show a movement in absolute
terms, i.e. a display range of 980 mm to 1020 mm is available.
MotionDsp Motion count indication. If standstill occurs with ON selected,
the character is displayed
MTime ms
MAmp kg
Standstill time;
Standstill is reported if Amplitude MAmp is not exceeded in
standstill time ”t”.
24 V
0 V
Warning
MAmp
Signal
Time
(Standstill time)
Standstill
MTi
me
