36
PME-MP55
HBM A0563-5.6 en
Group Parameter Meaning
IN/OUT PkMom
Max
PkMomMin
PkHldMax
PkHldMax
PkHldMin
Measuring signal
t
HoldRun Run
Function
Operating
mode
Peak value (Store1)
Current value
Hold
Trend of stored
value
Peak value operating mode
Amplitude
t
Measuring signal
Run Run
Function
Operating
mode
Current value
Hold
Current value operating mode
Amplitude
t
Run
CAN-Bus Baudrate 10 kB, 20 kB, 50 kB, 125 kB, 250 kB, 500 kB, 800 kB, 1000 kB
Address From 0 to 127 (8-bit)
Profile DS401 (Device Profile for I/O-Modules)
or DS404 (Device Profile for Measuring Devices and Closed
Loop Controller)
Output You may choose which signal is output over the CAN bus:
Gross, Net or Peak value Max/Min.
OutR. ms Output rate. Specifies the interval (in ms) at which a value is
sent over the CAN-interface.
