Inputs/Outputs (I/Os)
Terminal plug 3: This is equipped with 4 inputs which you can use to control
the functions of the PME.
Terminal plug 4: This has 4 outputs available.
Group Parameter Meaning
IN/OUT Output1...4 Outputs1..4 can be assigned the following functions:
Limit switches 1 to 4, standstill, errors, inactive
Mode
Out1...4
The output signal is inverted (pos.log) or not inverted
(neg.log).
Functions can be freely assigned to remotes (I/Os).
Function
Input value 0 V Input value 24 V
Taring Taring is started upon alternation from 0 V to 24 V
Zero
balance
Current measuring signal is set to zero upon alternation from
0 V to 24 V
PkMomMax Peak value operating mode
for PkMax
Current value operating mode
for PkMax
PkMomMin Peak value operating mode
for PkMin
Current value operating mode
for PkMin
PkHldMax Memory contents PkMax are
updated
Memory contents PkMax are
frozen
PkHldMin Memory contents PkMin
updated
Memory contents PkMin
frozen
ParaCo1 Selecting parameter sets and binary coded inputs
ParaCo2
Parameter set ParaCo2 ParaCo1
1 0 0
2 0 1
3 1 0
4 1 1
