48
PME-MP55
HBM A0563-5.6 en
Index
(hex)
Sub-
index
Name Format Attr. Values
Conditioning
2180 1 Tare value integer32 rw
2181 1 Zero balance value integer32 rw
2182 1 Memory mode for taring unsigned16 rw 6611: volatile
6610: permanent
2183 1 Memory mode for zeroing unsigned16 rw 6611: volatile
6610: permanent
2185 1 Zero reference integer32 rw
2190 1 Filter frequency unsigned16 rw 908: 0.05 Hz
914: 0.1 Hz
917: 0.2 Hz
921: 0.5 Hz
927: 1 Hz
931: 2 Hz
935: 5 Hz
941: 10 Hz
945: 20 Hz
949: 50 Hz
955: 100 Hz
958: 200 Hz
962: 500 Hz
2191 1 Filter characteristics unsigned16 rw 141: Butterworth
142: Bessel
21A0 1 Standstill monitoring by
time window
unsigned32 rw ms
21A1 1 Standstill monitoring by
amplitude
integer32 rw
21A2 1 Activate motion count
indication
unsigned16 rw 1: on
0: off
Analogue output
21C0 1 Mode of analogue output
(voltage/current)
unsigned16 ro 290: "10 V
291: " 20 mA
292: 4..20 mA
21C1 1 Signal at analogue output unsigned16 rw 214: Gross
215: Net
204: Max
205: Min
218: Peak-to-peak
21D0 1 Zero point of analogue
output phys. unit
integer32 rw Value e.g. in kN
21D1 1 Final value of analogue
output phys. unit
integer32 rw Value e.g. in kN
21D2 1 Zero point of analogue
output V
integer32 rw Value in V
21D3 1 Final value of analogue
output V
integer32 rw Value in V
