49
PME-MP55
HBMA0563-5.6 en
Index
(hex)
Sub-
index
Name Format Attr. Values
Limit switches
2210 1 Enable limit value 1 unsigned16 rw 1: yes
0: no
2211 1 Input signal for limit value 1 unsigned16 rw 214: Gross
215: Net
204: Min
205: Max
218: Peak-to-peak
2212 1 Direction of limit value 1 unsigned16 rw 130: Above limit
131: Below limit
2214 1 Starting delay LV 1 integer32 rw ms
2215 1 Cut-off delay LV 1 integer32 rw ms
2216 1 Switching level for limit
value 1
integer32 rw
2217 1 Hysteresis for limit value 1 integer32 rw
2218 1 Status of limit value 1 unsigned8 ro
2220 1 Enable limit value 2 unsigned16 rw 1: yes
0: no
2221 1 Input signal for limit value 2 unsigned16 rw 214: Gross
215: Net
204: Min
205: Max
218: Peak-to-peak
2222 1 Direction of limit value 2 unsigned16 rw 130: Above limit
131: Below limit
2224 1 Starting delay LV 2 integer32 rw ms
2225 1 Cut-off delay LV 2 integer32 rw ms
2226 1 Switching level for limit
value 2
integer32 rw
2227 1 Hysteresis for limit value 2 integer32 rw
2228 1 Status of limit value 2 unsigned8 ro
2230 1 Enable limit value 3 unsigned16 rw 1: yes
0: no
2231 1 Input signal for limit value 3 unsigned16 rw 214: Gross
215: Net
204: Min
205: Max
218: Peak-to-peak
2232 1 Direction of limit value 3 unsigned16 rw 130: Above limit
131: Below limit
