HBM MP55 - Page 51

50
PME-MP55
HBM A0563-5.6 en
Index
(hex)
Sub-
index
Name Format Attr
.
Values
2234 1 Starting delay LV 3 integer32 rw ms
2235 1 Cut-off delay LV 3 integer32 rw ms
2236 1 Switching level for limit value
3
integer32 rw
2237 1 Hysteresis for limit value 3 integer32 rw
2238 1 Status of limit value 3 unsigned8 ro
2240 1 Enable limit value 4 unsigned16 rw 1: yes
0: no
2241 1 Input signal for limit value 4 unsigned16 rw 214: Gross
215: Net
204: Min
205: Max
218: Peak-to-peak
2242 1 Direction of limit value 4 unsigned16 rw 130: Above limit
131: Below limit
2244 1 Starting delay LV 4 integer32 rw ms
2245 1 Cut-off delay LV 4 integer32 rw ms
2246 1 Switching level for limit value
4
integer32 rw
2247 1 Hysteresis for limit value 4 integer32 rw
2248 1 Status of limit value 4 unsigned8 ro
Peak values
2260 1 Input signal Min store unsigned16 rw 214: Gross
215: Net
2261 1 Input signal Max store unsigned16 rw 214: Gross
215: Net
2262 1 Envelope curve function
discharge
integer32 rw Display / s
2263 1 Enable peak-value store unsigned16 rw 1: enabled
2: disabled
Additional functions
2271 0 Hardware synchronisation unsigned16 ro 6700: Master
6701: Slave
2272 0 Sensitivity of keyboard unsigned16 rw 7601: low
7602: medium
7603: high
