Operating status:
LED
colour
Status Meaning
Measuring mode Bus mode
Green Steady
light
Ready to take
measurements
CAN Operational (PDO transfer possible)
Green Flashing Data being transmitted
over the interface
-
Yellow Steady
light
Ready to take
measurements
CAN bus Pre-Operational (PDO transfer not
possible)
LED
colour
Status Meaning Remedy
Measuring mode Bus mode
Red Flashing Measured value
overflow
LCD error
Transducer resistance
too low
-
Adapt range
Restart
Reduce excitation
voltage
Red Steady
light
Startup phase: not yet
ready to take
measurements,
calibration error
No internal
synchronisation
Original calibration error
CAN bus not ready for
communication
Wait
Connect
transducer, poss.
restart
Send PME to the
manufacturer
(HBM)
