HBM MP55 - Page 62

61
PME-MP55
HBMA0563-5.6 en
Effect of 10 K change in ambient tem-
perature
4)
on zero point full bridge
on zero point half bridge
on sensitivity
µV/V
µV/V
%
3 mV/V 50 mV/V 500 mV/V
1 10 100
10 20 100
0.05 0.05 0.05
Long-term drift over 48 hours, range
3 mV/V
(30 minutes after switching on)
µV/V 1
Analogue output
Impressed voltage
Permitted load resistance, min.
Internal resistance, max.
Impressed current
Permitted load resistance, max.
Internal resistance, min.
The analogue output can represent
gross, net, positive and negative peaks,
and peak-to-peak values.
V
kOhm
Ohm
mA
Ohm
kOhm
±10
10
10
"20; 4...20
500
100
Analogue output scale range min. 0.17 V at 100 % of amplifier input range
Analogue output scale range max 10 V at 3.67 % of amplifier input range
Noise voltage at output, typically mV
SS
10
Long-term drift over 48 hours
(30 minutes after switching on)
mV << 3
Effect of 10 K change in ambient tem-
perature (additional to the digital value
effect)
on zero point
Voltage
Current
on sensitivity
mV
µA
%
3
6
0.05
Limit switches
Number
Reference value
hysteresis
Adjustment accuracy
%
%
4
Gross, net, peak values
0...100
0.0033
Response time ms 1
Peak-value store
Number
Function
2
Positive, negative, peak-to-peak
Updating time ms 1
Clearing peak store ms 2
Recording current value/peak value ms 2
Envelope curve function discharge rate Unit/
sec
0 to 999999
4)
By reference to U
B
=5 V
