4 Modules
MX Modules A04089_07_E00_02 HBM: public 41
Channel
LED
Description
Description
(Connector 1, CAN bus)
Green Channel is ready CAN bus activated, CAN
data can be received
All orange Boot procedure is running
All orange
flashing
Download is active
Orange Connection is newly assigned;
transducer identification is
running
CAN data received but bus
is occasionally disturbed;
buffer overflow; individual
data loss
Green
flashing,
then green
TEDSdata is being read
Orange
flashing,
then green
Manual configuration; ignore
TEDS
Red No sensor connected; channel
error (incorrect parameterization,
connection error, invalid TEDS
data)
CAN bus error; CAN
interface in Bus OFF state;
CAN data cannot be
received or processed
