RESET
Used to reset charge in one or more channels. This command does not reset
microprocessor inside charge amplifier.
command RESET = value, [ch1, ch2, ..]
parameters:
value int 0 .. channel is in reset (its output value is 0 or
equal offset voltage)
1 .. channel is operational
ch1, ch2 .. int list of channels affected by this command. If
this parameter is omitted, then command is
applied to all channels.
response OK, RESET = value0 [channels( ch1, ch2, ..), value1
channels( ch3, ch4, ..)]
parameters:
value0 int If all channels are in the same state or this is
single channel amplifier, then value0 is state of
those cannels.
If there are channels with different state, then
value0 is 0, and then following list of all
channels with this value
ch1, ch2 int Numbers of channels, which have state 0
(reset)
value1 int Always 1.
ch3, ch4 int list of channels, which are operational
inquiry RESET = ?
response Same as response to command
help RESET?
response OK, RESET value [ch1, ch2, ..]
RESET_POLARITY
Used to set polarity of reset button.
command RESET_POLARITY polarity
parameters:
polarity int 0 .. logical low level on Reset pin is reset
1 .. logical high level on Reset pin is reset
response OK, RESET_ POLARITY = polarity
parameters:
polarity int See description above.
inquiry RESET_ POLARITY = ?
response OK, RESET_ POLARITY = polarity
parameters:
polarity int See description above.
help RESET_ POLARITY?
response OK, RESET_ POLARITY value[0..logical low goes is Reset,1..log.high is
Reset]
