HBM PACEline CMD600 - Page 36

36
CMD600
A2820−1.1 en
LED status
GREEN constant Amplifier running
RED constant Amplifier in reset
BLUE constant Amplifier connected over TELNET session
RED blinking with 1 s period Amplifier overloaded
BLUE blinking with 1 s period IP not configured
RED blinking with 0,5 s period Amplifier was powered up with easy teach
line active. Boot loader is running and
waiting for PC command. Time out for this
state is 10 s.
WHITE Amplifier was powered up with easy teach
line active. Boot loader has finished and
application is waiting 3 s. In this time
factory default can be started, if reset input
is pressed an released.
YELLOW blinking with 1 s period Auto scale procedure in 600000pC range
YELLOW blinking with 0.5 s period Auto scale procedure in 6000pC range
