9.5 CMD = 15, structure of Profinet telegram definition, depending on SW Versions
9.5.1 General
9.5.1.1 Error Message (indication by „Error occurred”)
Errors which are indicated in the Bit (Error occurred) like for example „Over Current” or „Cable Fraction” can be reset with
the following action :
- Set input signal for the hardware enable at the according module at terminal X3/1 (9) to „Low” and then go back to „High”
- Setting and resetting of the Bits (0x80) Bus-Disable
Mandatory condition for resetting an error is that the failure causing the error has been cleared or removed.
Error numbers:
The corresponding error numbers can be found in the respective manual of the DAC-4x(A).
Generally, the following error table is valid:
Slave (Module) Status
Description
Hi-Byte (DAT.1H) Low-Byte (DAT.1L)
0x0C
0x01
Error of Operation
0x0C
0x02
Wire break at FB1 (voltage/current depend on setting)
0x0C
0x03
Excess current or short circuit at the output stages (peak current >8A!)
0x0C
0x04
Wire break at FB2 (voltage/current depend on setting)
0x0C
0x05
Wire break at S1.05
(voltage/current depend on setting)
0x0C
0x06
Wire break at S1.06 (voltage/current depend on setting)
0x0C
0x0
7
Wire break at S1.0
7
(voltage/current depend on setting)
0x0C
0x08
Underload of the solenoid output (if monitoring is activated)
0x0C
0x0A
Timeout error
-
no Profinet command recognized
-
(defined with parameter E23)
0x0C
0x0B
Over current at feedback FB1 (current signal >22mA)
0x0C
0x0C
Over current at feedback FB2 (current signal >22mA)
0x0C
0x0F
Over current at set point S1.05
(current signal >22mA)
0x0C
0x10
Over current at set point S1.06 (current signal >22mA)
0x0C
0x1
1
Over current at set point S1.
07
(current signal >22mA)
0x0C
0x17
Selected Sensor need autocalibration.
Table 10: Error numbers
If parameter E 23 has a value not equal to 0 (Profinet timeout is activated). Depending on parameter E 26, there are
different responses from the device.
• E 26 = off (0)
The device reacts with a blinking enable LED about to long time between valid Profinet telegrams. Those
versions continue with work if a new valid telegram is detected. No separate acknowledges with the enable
signal is needed.
• E 26 = 1
The device reacts with a shining Error LED about to long time between valid Profinet telegrams. Those versions
do not continue with work if a new valid telegram is detected. A separate acknowledge with the enable signal is
needed.
Generally, the electronic discards every set point in error case and the outputs will be disabled.
9.5.1.2 Explanation for „Hardware Enable” and „Software Disable”:
Generally speaking, the hardware enable must be present („high” level) in order to get a signal (current) at the output
stages. Besides the hardware enable a software disable can be used in order to „override” the hardware enable. So even
if the hardware signal is present, with the according software command the module can be disabled!
This means that the hardware enable can be hardwired and the software disable can be used in order to drop the output
signal to zero or also in order to quit errors.
