02/11/98
16
HOW TO SET (Charged Voltage)
Your
Link 1000
automatically selects an appropriate Charged Voltage for 12 or
24 Volt liquid cells on power up. If you have gel cells, see Page 20 to set Battery Type.
An appropriate Charged Voltage for gel cells will be selected. If extremes of tempera-
ture are involved, or you have exotic batteries, here's how to change Charged Voltage:
1. Press SET for 5 seconds. SEL will appear in the numeric display.
2. Press SEL once. The light will come on and 13.2
[or 26.4*] will appear in the numeric display.
3. Press and hold SET. The numeric display will move up in 0.1 Volt
steps until 50.0 volts is displayed. The
display will then "wrap around" and
start counting up from 8.5 Volts. Stop at the
desired voltage.
4. After 10 seconds, the displayed
setting is stored in memory and
normal operation resumes.
HOW TO SET (Charged Current)
The
Link 1000
is factory set to use 2% of battery capacity as its Charging
Current Percentage. If you normally end charging before 2% is reached, or use a very
large battery bank, such as might be encountered in an alternative energy installation, a
different value may be appropriate. Here's how to change it:
1. Press SET for 5 seconds. SEL will appear in the numeric display.
2. Press SEL twice. The light will come on and 2 will
appear in the numeric display.
3. Press and hold SET. The numeric display will move up in 1 percent
steps until 7 percent is displayed. The
display will then "wrap around" and
start counting up from 1 percent.
4. After 10 seconds, the displayed
setting is stored in memory and
normal operation resumes.
