02/11/98
35
SET UP & HISTORICAL DATA
The following table is a summary of the major values that may be changed through
Set Up or by accumulating historical data. The column on the right is provided to write
down your set up values or historical data. Be sure and know these values before calling
for customer service. Multiply values by two for 24 Volt systems.
PARAMETER DEFAULT VALUE
BATTERY VOLTS
CHARGED
13.2 V ______________
BATTERY AMPS
CHARGED
2% ______________
BATTERY CAPACITY 200 A hrs ______________
POWER SHARE 30A (Off if Freedom 25) ______________
IDLE MODE 4W ______________
DATA VALUE
CEF ______________
# OF CEF RECALC'S ______________
AVG DEPTH OF DISCHARGE ______________
DEEPEST DEPTH OF DISCHARGE ______________
FUNCTIONS DEFAULT VALUE
DISPLAY SCAN (F01) Off ______________
DISPLAY SLEEP (F02) ON ______________
AMBIENT TEMP. (F03) 70
0
F ______________
AHRS/KWHRS (F04) Ahrs displayed ______________
ALT. ENERGY (F05) Off ______________
Manual CEF (F06) 95% (This value should
only be set if you do NOT
want your
Link 1000
to
automatically calculate CEF) ______________
TEMP. COEF. (F07) 0.5 ______________
PEUKERT EXP. (F08) 1.25 ______________
DISCH. FLOOR (F09) 100% ______________
BATTERY TYPE (F10) #1 LIQUID LEAD ACID ______________
SECOND BAT. (F11) Off ______________
SOFTWARE REV. (F15) *** ______________
TEMP. COMP. (F16) OFF
(Depends on F16 setting)
______________
