02/11/98
21
TEMPERATURE COMPENSATION TABLE
TEMP TYPE 0 TYPE 1 TYPE 2 TYPE 3
Liquid Gel 1 (Std) Gel 2 (Fast) AGM
0
F
0
C ACCEPT FLOAT ACCEPT FLOAT ACCEPT FLOAT ACCEPT FLOAT
120 49 12.5 12.5 13.0 13.0 13.0 13.0 12.9 12.9
110 43 13.6 12.7 13.5 13.0 14.0 13.4 13.9 12.9
100 38 13.8 12.9 13.7 13.2 14.1 13.5 14.0 13.0
90 32 14.0 13.1 13.8 13.3 14.2 13.6 14.1 13.1
80 27 14.2 13.3 14.0 13.5 14.3 13.7 14.2 13.2
70 21 14.4 13.5 14.1 13.6 14.4 13.8 14.3 13.3
60 16 14.6 13.7 14.3 13.8 14.5 13.9 14.4 13.4
50 10 14.8 13.9 14.4 13.9 14.6 14.0 14.5 13.5
40 5 15.0 14.1 14.6 14.1 14.7 14.1 14.6 13.6
30 -1 15.2 14.3 14.7 14.2 14.8 14.2 14.7 13.7
F04 -
TOGGLE DISPLAY BETWEEN A HR AND KWHR
DEFAULT OFF = A HR DISPLAY MODE
ON = KWHR DISPLAY MODE
When this function is selected the A hr display is changed to a kilowatt-hour display.
Kilowatt-hours are used by your
Link 1000
to determine if 100% of the energy consumed
from the battery has been returned. A recalculation of the CEF is not permitted unless this
counter is greater than 0.00 kWhr. This counter counts down during discharge and the
kWhrs consumed are displayed with a negative number. During charging it counts back up
with 100% efficiency. CEF recalculation is prevented until a positive number is in the kWhr
counter. This prevents premature CEF recalculation and Ahr reset. Kilowatt-hours are a
very precise measurement of energy removed from or returned to your battery bank.
F05 -
ALTERNATIVE ENERGY MODE
DEFAULT: OFF
ON = USE ALTERNATIVE ENERGY DEFAULTS
Turn this mode on if your
Link 1000
is used in Alternative Energy Systems.
This function reduces the time necessary to satisfy the charged parameters from 5 minutes
to 1 minute. If you're using a semi-mechanical photovoltaic controller, we strongly suggest
you also consider changing Charged Current to 4%. ( See How to Set
on page 16.)
Freedom units produced prior to serial #100,000 have temperature compensation only for
warm or cool environments. The temperature setup sets the voltages as per below:
TEMP TYPE0 (Liquid) TYPE1(Gel 1)
Accept Float Equalize Accept Float Equalize
Above 80
0
F 13.9 13.3 15.8 14.1 13.8 14.1
Below 80
0
F 14.4 13.5 16.3 14.4 13.8 14.4
