02/11/98
33
ERROR CODES
The following error codes are displayed when the
Link 1000
detects a problem. The
display alternates between the selected monitoring function and the Error Code. The Error
Code continues to flash until the error is corrected. Error codes are the same for all models.
CODE DEFINITION
E01 INVERTER HIGH DC/BATTERY VOLTAGE SHUTDOWN:
Battery Voltage has risen above 15.5V for 12V inverters or above 31V for
24V inverters. (Check all charging sources.)
E02 INVERTER LOW DC/BATTERY VOLTAGE SHUTDOWN:
Battery Voltage has dropped below 10.5V for 12V units or below 21V for 24V
inverters. (Check for dead battery or poor battery connections.)
E03 INVERTER OR CHARGER OVER TEMP SHUTDOWN:
Unit will reset automatically after it has cooled sufficiently. Be sure there is
adequate ventilation around the inverter.
E04 BATTERY OVERLOAD:
Caused by excessively discharged batteries or shorted battery. See section in
inverter owner's manual titled "Charging over-discharged batteries."
E05 AC BACKFEED:
AC power from an outside source has been fed to the AC output of the inverter.
Potentially damaging to the unit!! Disconnect incoming AC power and
correct immediately!! See a qualified electrician if you do not know how to
check for this condition.
E06 ELECTRONIC OVERLOAD:
Inverter overload caused by too large a load on the output of the inverter or
shorted inverter output. Reset by cycling the inverter on and off or connecting
AC power from an outside source.
E07 TRIAC CONTROL ERROR:
The Triac is used in the battery charging circuit. This error indicates that the
Triac has overheated, turn off charger and allow to cool. Be sure there is
adequate ventilation around the inverter.
E08 HIGH BATTERY VOLTAGE SHUTDOWN DURING CHARGING:
Check all charging sources (solar panels, alternators, other battery chargers,
etc.) for proper voltage. Reset by cycling the charger off and on.
E09 SPARE:
