02/11/98
44
Once you have completed ALL instructions on Page 41, insert the voltage sense
wire fuse (Blue Wire to fuse holder on battery #1).
Next, inset the voltage sense wire fuse to your starting battery (Violet Wire to fuse
holder on battery #2).
LAST, install the meter power fuse. (BLUE [and optional VIOLET] wire fuse[s]
first, RED wire fuse LAST!) The fuse should be in a fuse holder and should be connected
in a smooth motion. A "ragged" power up may cause a meter lock up. Both the light bar
and digital display should come on.
Next, plug in the phone cable that allows the
LINK 1000
to "talk" to the
Free-
dom
inverter/charger. Note that the AC status light should now come on if there's AC
power to the Freedom.
FACTORY DEFAULT SETTINGS
The
LINK 1000
comes on in the (Volts) mode with the display flashing to indicate
that it has been powered up from the de-powered state (E10). Left untouched for 10
minutes, the
LINK 1000
will go to "sleep", turning off the numeric display leaving only
the light bar on. This is a power saving feature. Touching any button (SEL, SET,
CHARGE, or INVERT) will clear the E10 message and return the
LINK 1000
to the
function it was in when it went to "sleep".
The
LINK 1000
is designed to work "out of the box". The factory default values are
appropriate for a moderate capacity 12V liquid lead acid battery and a typical user display
and function setup.
Often, the only change that must be made is setting the battery
capacity. You may also want to set the appropriate Peukert's exponent for your battery.
LINK 1000
factory default settings are:
1. Battery capacity set to 200 Amp-hours.
2. Time Remaining is set to a 4 minute average.
3. Battery Type = 0 (liquid cells)
4. Automatic Scanning of V, A, Ahrs, and Time is OFF.
5. Sleep Mode is ON. This turns the digital display off after 10 min.
6. Charge Efficiency Factor (CEF) equals 95% and learn CEF mode is on.
7. Charged Parameters: Voltage =13.2, Charged Current =2%. The battery
must exceed 13.2V and the current must be less, in Amps, than 2% of declared
capacity for 5 minutes for Your Meter to consider the battery full.
8. Peukert Exponent = 1.25.
9. Second Battery Voltage Sense is OFF.
10. Temperature Coefficient is 0.5.
11. Active Temperature Compensation is OFF.
START UP
