102 5 Programming: Tools
5.2 Tool Data
Tool table: Tool data required for automatic tool measurement
TIME2 Maximum tool life in minutes during TOOL CALL: If the current
tool age exceeds this value, the TNC changes the tool during the
next TOOL CALL (see also CUR.TIME).
Maximum tool age for TOOL CALL?
CUR.TIME Time in minutes the tool has been in use: The TNC automatically
counts the current tool age. A starting value can be entered for
used tools.
Current tool life?
DOC Comment on tool (up to 16 characters) Tool description?
PLC Information on this tool that is to be sent to the PLC PLC status?
PLC VAL Value of this tool that is to be sent to the PLC PLC value?
Abbr. Input Dialog
For a description of the cycles governing automatic tool
measurement, see the new Touch Probe Cycles Manual,
Chapter 4.
Abbr. Input Dialog
CUT Number of teeth (20 teeth maximum) Number of teeth ?
LTOL Permissible deviation from tool length L for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L). Input
range: 0 to 0.9999 mm
Wear tolerance: length ?
RTOL Permissible deviation from tool radius R for wear detection. If the
entered value is exceeded, the TNC locks the tool (status L). Input
range: 0 to 0.9999 mm
Wear tolerance: radius ?
DIRECT. Cutting direction of the tool for measuring the tool during rotation Cutting direction (M3 = –) ?
TT:R-OFFS For tool length measurement: tool offset between stylus center
and tool center. Preset value: Tool radius R (NO ENT means R).
Tool offset: radius ?
TT:L-OFFS Tool radius measurement: tool offset in addition to MP6530
between upper surface of stylus and lower surface of tool. Preset
value: 0
Tool offset: length ?
LBREAK Permissible deviation from tool length L for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Breakage tolerance: length ?
RBREAK Permissible deviation from tool radius R for breakage detection. If
the entered value is exceeded, the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
Breakage tolerance: radius ?
