440 12 MOD Functions
12.12 Selecting the Axes for Generating L Blocks
12.12 Selecting the Axes for
Generating L Blocks
Function
The axis selection input field enables you to define the current tool
position coordinates that are transferred to an L block. To generate a
separate L block, press the ACTUAL-POSITION-CAPTURE soft key.
The axes are selected by bit-oriented definition similar to programming
the machine parameters:
Axis selection %11111Transfer the X, Y, Z, IV and V axes
Axis selection %01111Transfer the X, Y, Z and IV axes
Axis selection %00111Transfer the X, Y and Z axes
Axis selection %00011Transfer the X and Y axes
Axis selection %00001Transfer the X axis
