388 10 Programming: Q Parameters
10.10 Preassigned Q Parameters
Deviation between actual value and nominal
value during automatic tool measurement with
the TT 130
Tilting the working plane with mathematical
angles: Rotary axis coordinates calculated by the
TNC
IVth axis
dependent on MP100
Q118
Vth axis
dependent on MP100
Q119
Coordinate axis Parameter value
Actual-nominal deviation Parameter value
Tool length Q115
Tool radius Q116
coordinates Parameter value
A axis Q120
B axis Q121
C axis Q122
