HEIDENHAIN TNC 426, TNC 430 367
10.8 Additional Functions
10.8 Additional Functions
Overview
Press the DIVERSE FUNCTION soft key to call the additional
functions. The TNC then displays the following soft keys:
Function Soft key
FN14:ERROR
Output error messages
FN15:PRINT
Unformatted output of texts or Q parameter values
FN16:PRINT
Formatted output of texts or Q parameter values
FN18:SYS-DATUM READ
Read system data
FN19:PLC
Transfer values to the PLC
FN20:WAIT FOR
Synchronize NC and PLC
FN25:PRESET
Set datum during program run
FN26:TABOPEN
Open a freely definable table
FN27:TABWRITE
Write to a freely definable table
FN28:TABREAD
Read from a freely definable table
