HEIDENHAIN TNC 426, TNC 430 217
8.3 Cycles for Drilling, Tapping and Thread Milling
U Set-up clearance Q200 (incremental value): Distance
between tool tip and workpiece surface.
U Depth Q201 (incremental value): Distance between
workpiece surface and bottom of hole
U Feed rate for plunging Q206: Traversing speed of
the tool during boring in mm/min
U Dwell time at depth Q211: Time in seconds that the
tool remains at the hole bottom
U Retraction feed rate Q208: Traversing speed of the
tool in mm/min when retracting from the hole. If you
enter Q208 = 0, the tool retracts at feed rate for
plunging.
U Workpiece surface coordinate Q203 (absolute
value): Coordinate of the workpiece surface
U 2nd set-up clearance Q204 (incremental value):
Coordinate in the tool axis at which no collision
between tool and workpiece (clamping devices) can
occur.
U Disengaging direction (0/1/2/3/4) Q214: Determine
the direction in which the TNC retracts the tool at the
hole bottom (after spindle orientation).
U Angle for spindle orientation Q336 (absolute
value): Angle at which the TNC positions the tool
before retracting it.
Example:
10 L Z+100 R0 FMAX
11 CYCL DEF 202 BORING
Q200 = 2 ;SET-UP CLEARANCE
Q201 = -15 ;DEPTH
Q206 = 100 ;FEED RATE FOR PLUNGING
Q211 = 0.5 ;DWELL TIME AT BOTTOM
Q208 = 250 ;RETRACTION FEED TIME
Q203 = +20 ;SURFACE COORDINATE
Q204 = 100 ;2ND SET-UP CLEARANCE
Q214 = 1 ;DISENGAGING DIRECTN
Q336 = 0 ;ANGLE OF SPINDLE
12 L X+30 Y+20 FMAX M3
13 CYCL CALL
14 L X+80 Y+50 FMAX M99
0 Do not retract tool
1 Retract tool in the negative reference axis
direction
2 Retract tool in the negative secondary axis
direction
3 Retract tool in the positive reference axis
direction
4 Retract tool in the positive secondary axis
direction
Danger of collision
Select a disengaging direction in which the tool moves
away from the edge of the hole.
Check the position of the tool tip when you program a
spindle orientation to the angle that you enter in Q336 (for
example, in the Positioning with Manual Data Input mode
of operation). Set the angle so that the tool tip is parallel to
a coordinate axis.
