8.3 Cycles for Drilling, Tapping and Thread Milling
U Set-up clearance Q200 (incremental value): Distance
between tool tip and workpiece surface
U Workpiece surface coordinate Q203 (absolute
value): Coordinate of the workpiece surface
U 2nd set-up clearance Q204 (incremental value):
Coordinate in the tool axis at which no collision
between tool and workpiece (clamping devices) can
occur.
U Feed rate for plunging Q206: Traversing speed of
the tool during drilling in mm/min
U Feed rate for milling Q207: Traversing speed of the
tool in mm/min while milling.
Example: NC blocks
25 CYCL DEF 264 THREAD DRILLNG/MLLNG
Q335=10 ;NOMINAL DIAMETER
Q239=+1.5 ;PITCH
Q201=-16 ;THREAD DEPTH
Q356=-20 ;TOTAL HOLE DEPTH
Q253=750 ;F PRE-POSITIONING
Q351=+1 ;CLIMB OR UP-CUT
Q202=5 ;PLUNGING DEPTH
Q258=0.2 ;ADVANCED STOP DISTANCE
Q257=5 ;DEPTH FOR CHIP BRKNG
Q256=0:2 ;DIST FOR CHIP BRKNG
Q358=+0 ;DEPTH AT FRONT
Q359=+0 ;OFFSET AT FRONT
Q200=2 ;SET-UP CLEARANCE
Q203=+30 ;SURFACE COORDINATE
Q204=50 ;2ND SET-UP CLEARANCE
Q206=150 ;FEED RATE FOR PLUNGING
Q207=500 ;FEED RATE FOR MILLING
