HEIDENHAIN TNC 426, TNC 430 305
8.6 SL cycles
21 LBL 1 Contour subprogram 1: left pocket
22 CC X+35 Y+50
23 L X+10 Y+50 RR
24 C X+10 DR-
25 LBL 0
26 LBL 2 Contour subprogram 2: right pocket
27 CC X+65 Y+50
28 L X+90 Y+50 RR
29 C X+90 DR-
30 LBL 0
31 LBL 3 Contour subprogram 3: square left island
32 L X+27 Y+50 RL
33 L Y+58
34 L X+43
35 L Y+42
36 L X+27
37 LBL 0
38 LBL 4 Contour subprogram 4: triangular right island
39 L X+65 Y+42 RL
40 L X+57
41 L X+65 Y+58
42 L X+73 Y+42
43 LBL 0
44 END PGM C21 MM
