376 10 Programming: Q Parameters
10.8 Additional Functions
0: mirroring not active
+1: X axis mirrored
+2: Y axis mirrored
+4: Z axis mirrored
+64: U axis mirrored
+128: V axis mirrored
+256: W axis mirrored
Combinations = sum of individual axes
4 1 Active scaling factor in X axis
4 2 Active scaling factor in Y axis
4 3 Active scaling factor in Z axis
4 7 Active scaling factor in U axis
4 8 Active scaling factor in V axis
4 9 Active scaling factor in W axis
5 1 3D ROT A axis
5 2 3D ROT B axis
5 3 3D ROT C axis
6 - Tilted working plane active / inactive (-1/0)
Active datum shift, 220 2 1 X axis
2 Y axis
3 Z axis
4 A axis
5 B axis
6 C axis
7U axis
8 V axis
9 W axis
Traverse range, 230 2 1 to 9 Negative software limit switch in axes 1 to 9
3 1 to 9 Positive software limit switch in axes 1 to 9
Group name, ID No. Number Index Meaning
