378 10 Programming: Q Parameters
10.8 Additional Functions
2 Center point Y-axis (REF system)
3 Center point Z axis (REF system)
21 - Probe contact radius
Measuring touch probe, 350 30 - Calibrated stylus length
31 - Stylus radius 1
32 - Stylus radius 2
33 - Setting ring diameter
34 1 Center misalignment in ref. axis
2 Center misalignment in minor axis
35 1 Compensation factor for 1st axis
2 Compensation factor for 2nd axis
3 Compensation factor for 3rd axis
36 1 Power ratio for 1st axis
2 Power ratio for 2nd axis
3 Power ratio for 3rd axis
Last touch point in TCH PROBE-
cycle 0 or last touch point from
manual operating mode, 360
1 1 to 9 Position in the active coordinate system in axes 1 to 9
2 1 to 9 Position in the REF system in axes 1 to 9
Value from the active datum table in
the active coordinate system, 500
Datum
number
1 to 9 X axis to W axis
REF value from the active datum
table, 500
Datum
number
1 to 9 X axis to W axis
Datum table selected, 505 1 - Acknowledgement value = 0: No datum table active
Return code = 1: Datum table active
Data from the active pallet table, 510 1 - Active line
2 - Palette number from PAL/PGM field
Machine parameter exists, 1010 MP
number
MP index Acknowledgement value = 0: MP does not exist
Return code = 1: MP exists
Group name, ID No. Number Index Meaning
