HEIDENHAIN TNC 426, TNC 430 449
13.1 General User Parameters
External data transfer
Integrating TNC interfaces EXT1 (5020.0)
and EXT2 (5020.1) to an external device
MP5020.x
7 data bits (ASCII code, 8th bit = parity): +0
8 data bits (ASCII code, 9th bit = parity): +1
Block Check Character (BCC) any: +0
Block Check Character (BCC) control character not permitted: +2
Transmission stop through RTS active: +4
Transmission stop through RTS inactive: +0
Transmission stop through DC3 active: +8
Transmission stop through DC3 inactive: +0
Character parity even: +0
Character parity odd: +16
Character parity not desired: +0
Character parity desired: +32
11/2 stop bits: +0
2 stop bit: +64
1 stop bit: +128
1 stop bit: +192
Example:
Use the following setting to adjust the TNC interface EXT2 (MP 5020.1) to
an external non-HEIDENHAIN device:
8 data bits, any BCC, transmission stop through DC3, even character
parity, character parity desired, 2 stop bits
Input for MP 5020.1: 1+0+8+0+32+64 = 105
Interface type for EXT1 (5030.0) and
EXT2 (5030.1)
MP5030.x
Standard transmission: 0
Interface for blockwise transfer: 1
3-D touch probes and digitizing
Select touch probe
(only with option for digitizing with
measuring touch probe)
MP6200
Triggering touch probe: 0
Measuring touch probe: 1
Select signal transmission MP6010
Touch probe with cable transmission: 0
Touch probe with infrared transmission: 1
Probing feed rate for triggering touch
probes
MP6120
1 to 3 000 [mm/min]
Maximum traverse to first probe point MP6130
0.001 to 99 999.9999 [mm]
Safety clearance to probing point during
automatic measurement
MP6140
0.001 to 99 999.9999 [mm]
