468 13 Tables and Overviews
13.3 Technical Information
Input range n Minimum 0.1µm (0.00001 in.) or 0.0001°
n Maximum 99 999.999 mm (3.937 in.) or 99 999.999°
Input format and unit of TNC functions
Positions, coordinates, circle radii, chamfer
lengths
-99 999.9999 to +99 999.9999
(5.4: places before decimal point, places after decimal point) [mm]
Tool numbers 0 to 32 767.9 (5.1)
Tool names 16 characters, enclosed by quotation marks with TOOL CALL. Permitted
special characters: #, $, %, &, -
Delta values for tool compensation -99.9999 to +99.9999 (2.4) [mm]
Spindle speeds 0 to 99 999.999 (5.3) [rpm]
Feed rates 0 to 99 999.999 (5.3) [mm/min] or [mm/rev]
Dwell time in Cycle 9 0 to 3 600.000 (4.3) [s]
Thread pitch in various cycles -99.9999 to +99.9999 (2.4) [mm]
Angle of spindle orientation 0 to 360.0000 (3.4) [°]
Angle for polar coordinates, rotation, tilting
the working plane
-360.0000 to 360.0000 (3.4) [°]
Polar coordinate angle for helical
interpolation (CP)
-5 400.0000 to 5 400.0000 (4.4) [°]
Datum numbers in Cycle 7 0 to 2 999 (4.0)
Scaling factor in Cycles 11 and 26 0.000001 to 99.999999 (2.6)
Miscellaneous functions M 0 to 999 (1.0)
Q parameter numbers 0 to 399 (1.0)
Q parameter values -99 999.9999 to +99 999.9999 (5.4)
Labels (LBL) for program jumps 0 to 254 (3.0)
Number of program section repeats REP 1 to 65 534 (5.0)
Error number with Q parameter function
FN14
0 to 1 099 (4.0)
Digitizing parameters in digitizing cycles 0 to 5.0000 (1.4) [mm]
Spline parameter K -9.99999999 to +9.99999999 (1.8)
Exponent for spline parameter -255 to 255 (3.0)
Surface-normal vectors N and T with 3-D
compensation
-9.99999999 to +9.99999999 (1.8)
TNC Specifications
