9.4 Cable ties
Designation T18RA50 PA66HS NA 2000
T18RA3500 PA66HS NA 3500
T18RA50 PA66HSW BK 2000
T18RA3500 PA66HSW BK 3500
T18RA3500 PA46 NA 3500
Article number 120-40019
120-50009
120-40020
120-50010
120-46009
Minimum binding force 80 N
Comparable cable tie: T18R
Material Polyamide 6.6 Polyamide 4.6
Quality Heat-stabilized UV-stabilized
Heat-stabilized
High-temperature-resistant
Color Natural (NA) Black (BK) Natural (NA)
Colored cable ties available on request
Operating temperature –40 °C to +105 °C –40 °C to +105 °C –40 °C to +150 °C
briefly to +145 °C (500 h) +145 °C (500 h) +195 °C (500 h)
Approvals/standards SAE AS23190 (MIL MS 3367) - MS3367-42
HellermannTyton UL file No.: E65344
Flammability UL94 V2
better than 100 mm/min.
UL94 V2
better than 100 mm/min.
UL94 V2
Weathering Good weather-resistance under
normal climate conditions
The effects caused by exposure to
ultraviolet light are considerably
reduced by the addition of carbon.
The addition of a stabilizer prevents
surface oxidation.
Good weather-resistance under
normal climate conditions
Resistance to ageing No discernible ageing in conditions
of typical use in interiors.
Even with strong sunlight no
significant loss of tensile strength is
discernible.
No discernible ageing in conditions
of typical use in interiors.
Chemicals Very good resistance to oils, greases, lubricants, aliphatic and aromatic hydrocarbons and conventional motor-vehicle
fuels. Resistant to many organic substances, including for example ketones, ester, halogenated compounds
Not resistant to strong mineral acids and/or oxidising chemicals, especially at high temperatures
*
* Halogen-free as per prohibitions of the GADSL list and notification obligations of the SVHC list
