ATTRVAL Format: A[max4]
„ECID_37“ Parameter 37 MID area
„ECID_38“ Parameter 38 Test after software reset
„ECID_40“ Parameter 40 Transponder load duration (write-mode)
„ECID_41“ Parameter 41 Delay time between read cycles
„ECID_42“ Parameter 42 CarrierIDOffset
„ECID_43“ Parameter 43 CarrierIDLength
„ECID_44“ Parameter 44 FixedMID
„ECID_45“ Parameter 45 MIDFormat
„ECID_75“ Parameter 75 DIP switch state (read only)
„ECID_80“ Parameter 80 Auto adjust value antenna port 1 (read only)
„ECID_81“ Parameter 81 Auto adjust value antenna port 2 (read only)
„ECID_82“ Parameter 82 Auto adjust value antenna port 3 (read only)
„ECID_83“ Parameter 83 Auto adjust value antenna port 4 (read only)
„ECID_97“ Parameter 97 Default protocol (read only)
„ECID_98“ Parameter 98 Protocol change allowed
„ECID_99“ Parameter 99 Customer Code
Header attribute definitions:
„HeadStatus“ Current state corresponds to „OperationalStatus“
„HeadID“ Headnumber 00-xx (2Ziffern)
Where used S5F1
Value of the specified attribute.
CIDRW-attribute definitions:
„Configuration” Number of antenna ports „04“
„AlarmStatus” Current CIDRW sub-state of the
ALARM STATUS „0“ …NO
„1“ …ALARMS
„OperationalStatus“ Current CIDRW sub-state of IN OPERATION
„IDLE“ …reader is rest mode
„BUSY“ …reader is busy
„MANT“ …maintenance mode
„SoftwareRevisionLevel“ Revision (version) of the software (max. 8 bytes)
„SERIALNUM“ serial number string (max. 15 bytes)
„HARDWARE“ String of the hardware release (max. 10 bytes)
