Software version
Where used S1F2
Result information about the status of the request for the service request.
„NO“ Normal Operation
Indicates the success of the requested operation.
„EE“ Execution error
Transponder data cannot be read. MID sequence cannot be read, as valid ASCII characters were not
found exclusively in the defined MID area. However, the condition of the facilities is normal.
„CE“ Communication error
Syntax error in message, message format, or value.
„HE“ Hardware error
Error in the head of the ID reader / writer, head of the ID reader / writer is deactivated.
„TE“ Transponder error, reading / writing unsuccessful (Tag Error)
„NT“ No transponder detected in the antenna area. (No Tag)
Where used S18F2, S18F4, S18F8, S18F10, S18F12, S18F14
Specifies an operation to be performed by the subsystem. Used to distinguish between the various
subsystem commands displayed.
„ChangeState“ … change status
„GetStatus“ … query staus
„Reset“ … reset CIDRW
„PerformDiagnostics“ … A diagnosis is made.
„ADJUST“ … triggers an automatic alignment of the antenna.
„HERMOSDefParams“ … Basic setting of the readers parameters.
„SetLED „ … Set one of the device LEDs.
CPVAL‘s 1 <LEDStatus>
2 <Timeout>
3 <LEDNo>
Where used S18F13
SSCMD Format: A[max 18]
SOFTREV Format: A[max 6]
SSACK Format: A[2]
