The status list provides information about the system status.
Consists of „PM Information“ and the current values of the CIDRW attributes „AlarmStatus“, „Operating
Status“ and „HeadStatus“.
Status list
L,4
<PMInformation>
<AlarmStatus>
<OperatingStatus>
<HeadStatus>
Where used S18F2, S18F4, S18F8, S18F10, S18F12, S18F14
The TargetID is defined with 2 decimal ASCII characters and corresponds to the antenna connections. The
2-digit target ID (Head-ID) is used to set the antenna port 1 to 4 for which the action is to be carried out.
(see Adressing the antenna ports). The use of the 4-digit TARGETID is currently not supported.
Where used S18F1, S18F3, S18F4, S18F7, S18F9, S18F11, S18F13
Status list Format: A[2]
TARGETID Format: A[2]
