INSTRUMENTS AND INDICATORS
The indicators are in the speedometer
panel above the headlamp. The functions
are as below :
PARTS FUNCTION
Sl. No.
1
2
3
4
5
Description Function
Odometer Shows accumulated mileage
Hi beam indicator Light glows when headlamp is in Hi beam
Speedometer Indicates driving speed
Turn signal indicator Flashes when turn signal switch is operated
14
FUEL GAUGE
When the fuel gauge (1) needle enters the
red band (2), fuel will be low and you
should refill the tank as soon as possible.
The amount of fuel left in the tank when
the needle enters the red band is
approximately 1.2 Litres.
(1) Fuel gauge (2) Red band
4
6
3
1
2
2
1
5
6 Fuel gauge Indicates approximate fuel quantity
Side stand indicator
Light glows when the side stand is down
