Installation
Installation can be done in the reverse
order of removal.
Rear view mirror
33
3
3
(1) Dust cover (2) Lock nut
(3) Rear view mirror
1
2
(3) Connector (4) Front upper cover
3
Removal
2. L o o s e n the rear v i e w mirror
approximately 2 turns.
Installation
2. Loosen the lock nut (2) until it will no
longer turn.
1. Slide the dust cover (1).
1. Install the rear view mirror until it will
no longer turn.
3. Loosen the rear view mirror (3) and
remove it.
3. Adjust the rear view mirror.
4. Tighten the lock nut.
To open the right side rear view mirror the
threads are to be loosened in clockwise
direction and tightened in counter
clockwise direction.
Headlamp case
Removal
1. Remove the rear view mirror.
2. Remove screw (1).
NOTE
3. Disconnect the left and right
turn signal lamp wiring connector (3)
from the front upper cover (4).
4
