HERO PLEASURE - Body Cover

31
(5) Screws/washers (6) Body cover (7) Clip
5
7
6
(1) Screws/washers (2) Rear center cover
1
2
(4) Screws/washers
4
4. Remove the screws/washers (4) from
the center compartment.
5. Remove the screws/washers (5) from
both the side of the body cover (6).
(3) Screws
3
Body cover
Removal
1. Open the seat (page 26)
2. Remove the screws/washers (1) from
rear center cover and remove the cover (2).
6. Remove the clip (7) from both the side
7. Remove the body covers.
of the vehicle.
3. Remove the screws/washers (3) from
the rear side of the body cover.
