29
(1) Side stand indicator
1
BOOT LAMP
Opening and closing the Seat Lock, see
(page 26).
A boot lamp (1) is provided in the center
compartment. This boot lamp will be
functional only when the seat is open.
SIDE STAND SWITCH
A side stand switch (2) is provided on the
side stand, if the side stand is down
(Ignition switch “ON”), the switch
enables the side stand indicator lamp to
glow on the speedometer panel.
(2) Side stand switch
2
If the side stand is down (Ignition switch “ON”), an
indicator lamp glows in the speedometer panel.
For the safety of the customer a side stand
indicator (1) is provided.
SIDE STAND INDICATOR
1
A automated switch (2) is provided on the
center compartment, which enables the
boot lamp to glow when the seat is in open
condition and goes off automatically when
the seat is closed.
BOOT LAMP SWITCH
2
(1) Boot lamp (2) Switch
