HERO PLEASURE - Right Handlebar Controls; Left Handlebar Controls

The switch has two positions.
1. Headlamp switch
When the starter switch is pressed, the
starter motor cranks the engine. See
(page 35) for the starting procedure.
The Headlamp operates only when the
engine is running.
2. Starter switch
The starter switch (2) is next to the
throttle grip.
(1) Headlamp switch (2) Starter switch
25
2. Turn signal switch
Press the switch upwards for High Beam
and downwards for Low Beam.
Press the switch to operate the horn.
Shift the turn signal switch sideways for
Right/Left indications and leave it to come
back to its normal position on its own.
3. Horn switch
IMPORTANT : To switch “OFF” the turn
signal after completing the turn, gently
push inside as directed on the switch.
1. Dimmer switch
(1) Dimmer switch
(2) Turn signal switch
(3) Horn switch
1
2
1
2
3
LEFT HANDLEBAR CONTROLS
RIGHT HANDLEBAR CONTROLS
white
Position lamp
Tail / Stop lamp
Fuel gauge lamp
Speedometer lamp
Headlamp “ON”
