(1) Drain Plug
4. The spring (3) and oil strainer
screen (4) will come out when the o i l
strainer screen cap is removed.
(3) Spring (4) Oil strainer screen
(5) O-ring
3. Remove the oil strainer screen cap (2).
(2) Oil strainer screen cap
55
6. Check that the oil strainer screen,
sealing rubber and cap o-ring (5) are in
good condition.
7. Install the oil strainer screen, spring
and oil strainer screen cap. Install the
drain plug
9. Install the oil level dipstick.
5. Clean the oil strainer screen.
8. Fill crankcase with the recommended
grade of oil :
At draining : 0.70 litre
At engine disassembly : 0.80 litre
2
1
3
4
5
