28
Left handlebar controls
1. Headlamp dimmer switch/
Press the switch (1) upwards for high beam
“ ” downwards for low beam “ ”.
The headlamp operates only when the engine
is running.
HANDLEBAR SWITCHES CONTROL
Pass switch
Press the switch to operate the horn (3).
Shift the turn signal switch (2) sideways for
right/left indications and leave it to come
back to its normal position on its own.
Press the pass switch to “PASS” position to
operate the pass lamp.
IMPORTANT : To switch “OFF” the turn
signal after completing the turn, gently push
the switch inside.
3. Horn switch ( )
2. Turn signal lamp switch ( )
(1) Ignition key
1
(1) Headlamp dimmer switch/Pass switch
(2) Turn signal switch (3) Horn switch
4. Clutch switch
There is a clutch switch (4) provided for the
safety of the rider. The vehicle cannot be
started by electric starter switch until the clutch
lever is operated when the vehicle is engaged
in gear.
32
(4) Clutch switch
4
1
