FRONT VIEW
1. Front fender
3. Right position lamp
4. Front visor
2. Front right turn signal lamp 6. Left position lamp
7. Front left turn signal lamp
8. Oil cooler
5. Headlamp
1
2
4
*Accessories and features shown may not be part of standard fitment.
2
VEHICLE VIEWS
5
3
6
7
8
