STOP LAMP SWITCH
The stop lamp switch (1) must be adjusted so
that stop lamp glows when rear brake is
applied. The procedure for adjusting stop
lamp is as follows :
•
Turn the ignition switch to the “ON” ( )
position.
(1) Headlamp adjusting screw
1
(1) Stop lamp switch (A) Advance
(2) Adjusting nut (B) Retard
A
B
•
Turn the adjusting nut (2) to position stop
lamp switch at a point where the stop lamp
glows once the brake pedal is depressed.
Turn the adjusting nut in direction (A) to
advance switch timing or in direction (B) to
retard switch timing.
•
Headlamp adjustment is done by the
loosening or tightening the screw (1)
located behind the headlamp assembly.
•
Park the vehicle on it main stand on level
ground.
•
Adjust the headlamp beam by loosening or
tightening the screw (1) located behind the
headlamp assembly for correct focus
adjustment.
Headlamp is factory pre-set. However in case
of adjustment required, please follow the
steps as given below:
HEADLAMP FOCUS ADJUSTMENT
1
2
