Ÿ Slightly loosen the engine oil check bolt (4)
and check the engine oil entry into the
cylinder head cover.
Ÿ Park the vehicle on its main stand.
Ÿ Do top up if oil level reaches towards the
lower level mark or every 3000 km
whichever is earlier.
Ÿ Start the engine & let it idle for 3-5
minutes.
(1) Oil level dipstick (2) Upper level mark
(3) Lower level mark
46
2
3
1
ENGINE OIL
Top up process
Check engine oil level each day before
operating the vehicle. The oil level dipstick (1)
is on the right crankcase cover for measuring
oil level. Oil level must be maintained between
the upper (2) and lower (3) level marks on
the oil level dipstick.
Ÿ Tide Water Oil Co. (India) Ltd.
BRAND: Hero 4T plus
Manufactured by:
Engine oil level inspection/
Ÿ Bharat Petroleum Corporation Limited.
Ÿ Savita Oil Technologies Limited.
GRADE: SAE 10W 30 SL Grade
Use hero genuine engine oil or recommended
grade oil.
OIL CAPACITY : 1360 ml
(JASO MA2).
Ÿ After checking the oil circulation, tighten the
engine oil check bolt.
Ÿ Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
Ÿ Remove the oil level dipstick and check the
oil level.
Ÿ If required, add the specified oil up to the
upper level mark. Do not overfill.
Ÿ Stop the engine and wait for 2-3 minutes.
Ÿ Quantity of oil to be filled is 1170 ml
(approx.) during oil change (when right
crankcase cover is not removed).
(4) Engine oil check bolt
4
UPPER
LOWER
