HERO XTREME 200S PROGRAMMED FI - Battery Installation and Fuse Replacement; Battery Installation Steps; Fuse Box Locations and Types

(6) Battery
•
Pullout the battery (6) from the battery box.
68
Refer to the safety precautions on (page 41).
Spare fuse (4) : 15A, 10A
Main fuse (3) : 15A, 10A
Battery installation
FUSE REPLACEMENT
Ÿ Reinstall in the reverse order of removal. Be
sure to connect the (+)ve terminal first, then
the (-)ve terminal.
Location: The fuse boxes (A) and (B) are
below the seat.
Main fuse (1) : 15A, 10A
Fuse type: Blade fuse
Spare fuse (2) : 15A, 10A
Fuse box (A)
Ÿ bolt and other Check all fasteners are secure
properly.
Fuse box (B)
(3) (-)ve terminal (4) (+)ve terminal
(5) Battery belt
3
4
6
5
(1) Left side cover screws (2) Side cover
2
1
