50
•
Remove the air cleaner element (4).
4
(4) Air cleaner element
NOTE
Align the tabs of air cleaner cover before
installing screws & the cover.
•
Clean the air cleaner housing using a shop
towel.
•
Install the new air cleaner element.
•
Install the air cleaner element cover.
•
Install the seat ).(page 33
Remove the drain tube (1) and drain the
deposit into a container.
Follow the above process more frequently
when riding in rain or at full throttle.
Air cleaner drain tube cleaning
•
Connect the fuse boxes.
(2) Air cleaner cover screws (3) Cover
3
2
CAUTION
!!
• wet, paper pleated Never wash or clean the
type filter. Replace filter element once in
every 15000 km.
• Replace it earlier if it becomes very dirty,
damage on surface or on the sealing area.
