HERO XTREME 200S PROGRAMMED FI - Vehicle Views - Right Side; Braking System Component Identification; Engine Component Identification; Other Component Identification

(1) Rear master cylinder
(2) Rear brake pedal
(3) Kick starter pedal
(4) Oil level dipstick
(5) Front caliper assembly
(7) Rear brake fluid reservoir
(6) Front disc
(8) Seat
(9) Fuse box
(10) Document, Tool kit/First aid kit
compartment
(11) Rear caliper assembly
(12) Exhaust muffler
(13) Rear disc
RIGHT SIDE VIEW
10
6
1
5 6
8
12
13
11
9
*Accessories and features shown may not be part of standard fitment.
