Hesai Pandar64 User Manual

Power consumption ② 22 W (typical)
Operating temperature –20℃ to 65℃
Storage temperature –40℃ to 85℃
Weight 1.52 kg
Data I/O
Data transmission 100BASE-TX, slave mode
Measurements Distance, azimuth angle, and reflectivity
Valid data points Single Return: Ê: 1 152 000 points/sec
Dual Return: Ê: 2 304 000 points/sec
Point cloud data rate Single Return: Ê 29.76 Mbps
Dual Return: Ê 59.52 Mbps
Clock source GPS/PTP (1588v2, 802.1AS, 802.1AS Automotive)
PTP clock accuracy ≤1 μs
PTP clock drift ③ ≤1 μs/s

Specifications are subject to change. Please refer to the latest version of this manual.
Notes to specifications
① Ranging accuracy
•
Defined as the average range error across all channels.
•
May vary with range, temperature, and target reflectivity.
② Power consumption
•
Not including accessories such as the connection box.
•
The external power supply should be able to provide at least 22 W.
③ PTP clock drift Defined as the drift at a constant temperature after the lidar (slave clock) loses connection to the PTP master.
Pandar64
-14-
