Hesai Pandar64 User Manual

1.4. Specifications
Sensor
Scanning method Mechanical rotation
Channel number 64
Ranging capability 0.3 to 200 m (at 10% reflectivity)
Ranging accuracy ① ±5 cm (0.3 to 1 m), ±2 cm (1 to 200 m)
Horizontal FOV 360°
Horizontal resolution 0.2° (10 Hz), 0.4° (20 Hz)
Vertical FOV 40° (–25° to +15°)
Vertical resolution 0.167° Ê (Channels 6 to 54)
1° Ê (Channels 5 to 6, 54 to 62)
Frame rate 10 Hz, 20 Hz
Return mode Single Return: Last/Strongest
Dual Return: Last and Strongest
MECHANICAL/ELECTRICAL/OPERATIONAL
Wavelength 905 nm
Laser class Class 1 Eye Safe
Ingress protection IP6K7
Dimensions Height: 116.7 mm
Top/bottom: Φ118.0/116.0 mm
Rated voltage range DC 9 to 48 V
Pandar64
-13-
