Hesai Pandar64 User Manual

4.3.3. Multi-section FOV
For each channel, input multiple (≤10) sets of Start Angles and End Angles to form multiple continuous angle ranges.
The [ Status ] buttons for each channel:
•
are gray by default, indicating that the angle range is [0°, 360°].
•
To activate the angle range in the table, click the corresponding button to make it green.
Click the [ Enable/Disable All ] button to activate/deactivate the angle ranges of all channels.
Azimuth FOV Setting Multi-section FOV
ÊEnable/Disable AllÊ
Status Channel
Azimuth FOV 1 Azimuth FOV 2
…
Azimuth FOV 10
Start Angle End Angle Start Angle End Angle … Start Angle End Angle

1 0.0 0.0 0.0 0.0 … 0.0 0.0

2 0.0 0.0 0.0 0.0 … 0.0 0.0

… 0.0 0.0 0.0 0.0 … 0.0 0.0

64 0.0 0.0 0.0 0.0 … 0.0 0.0
ÊSaveÊ
Pandar64
-61-
