Device overview
Rating plate
Ambient conditions (EN / IEC 61010-1):
Installation site indoors only
Altitude up to 2000 m above sea level
Ambient temperature 2°C to 40 °C
Humidity maximum relative humidity 80%for temperatures up to 31°C,
decreasing linearly to 50%relative humidity at 40°C.
Overvoltage category
(IEC 60364-4-443)
II
Pollution level 2
Device protection class I
not suitable for use in potentially explosive atmospheres.
EMC:
Emitted EM interference,
EM interference immunity
EN/IEC61326-1
Class B
FCC Class B EN/IEC61326-1
Class B
FCC Class B
Noise level
(rotor-dependent)
£50dB(A) £55dB(A)
Dimensions:
Width 261 mm
Depth 353 mm
Altitude 228 mm
Weight approx.9kg approx.11kg
23
10
11
17
12
13
15
14
16
1819
24
20
22
21
2 43 5 6 7 8 91
Fig. 1: Rating plate
1 Item number
2 Serial number
3 Revision
4 Equipment number
