Software operation
RCF indicator
3. Use the [t] buttons to set the desired value.
Adjustable from 1to99minutes in 1minute increments.
The parameters t/min and t/sec must be set to zero to set continuous
operation.
🡆 ‘--:--’ is displayed.
4. Press the [SELECT] button.
🡆 Runtime in ‘t/sec’ is displayed.
5. Use the [t] buttons to set the desired value.
Adjustable from 1 to 59 seconds, in 1 second increments.
The parameters t/min and t/sec must be set to zero to set continuous
operation.
🡆 ‘--:--’ is displayed.
6. Press the [SELECT] button.
🡆 Speed ‘RPM’ is displayed.
7. Use the [t] buttons to set the desired value.
A numerical value from 200RPM to the maximum rotor speed can be
set.
Adjustable in 10 second increments.
8. Press the [SELECT] button.
🡆 The DEC brake level is displayed.
fast: short ramp-down time
slow: long ramp-down time
9. Use the [t] buttons to set the desired value.
10. Press the [START/PULSE] button.
🡆 The settings are stored.
1. If required: Press the [RCF] button to select the RCF indicator.
🡆 Press the [RCF] button to toggle between the two parameters
RPM ( ‘RPM’ ) and RCF ( ‘>RCF<’ ).
2. Press the [SELECT] button.
🡆 Runtime in ‘t/min’ is displayed
3. Use the [t] buttons to set the desired value.
Adjustable from 1to99minutes in 1minute increments.
The parameters t/min and t/sec must be set to zero to set continuous
operation.
🡆 ‘--:--’ is displayed.
4. Press the [SELECT] button.
🡆 Runtime in ‘t/sec’ is displayed.
5. Use the [t] buttons to set the desired value.
Adjustable from 1 to 59 seconds, in 1 second increments.
The parameters t/min and t/sec must be set to zero to set continuous
operation.
🡆 ‘--:--’ is displayed.
6. Press the [SELECT] button.
🡆 Centrifuging radius ‘RAD/mm’ is displayed.
